GPO-3 is a thermoset polyester sheet material with glass reinforcement. GPO-3 is resilient to impacts, robust, stiff, and dimensionally stable. Exceptional electrical characteristics of the material include flame, arc, and track resistance. It is frequently utilised for electrical insulating purposes. Additionally, GPO-3 is employed in mechanical applications that need it to be strong, rigid, dimensionally stable, and reasonably priced.
1. Our Production
2. Product Description
A glass reinforced thermoset polyester with good electrical characteristics in ark and track resistance is GPO3 polyester glass laminate. It is suitable for a wide range of applications in the mechanical and electro-mechanical fields thanks to its exceptional strength, dimensional stability, and stiffness. The substance is flame-resistant since it complies with Nema GPO3 specifications.
Due to its great rigidity and stiffness, GPO3 is simple to process. It is popular for bespoke structural elements and components that need great durability and stability due to the same qualities. We have a number of internal CNC facilities, including milling, turning, sawing, and drilling tools, that enable us to transform this material.
3. Quick Details
|
Standards |
IEC893/EN 60893 Grade: UPGM 203 NEMA L1: GPO-3 |
|
Size |
1000mmx2000mm(39in x 78in) 1250mmx2000mm(49in x 78in) 1250mmx2500mm(49in x 98in) Customized size within 1250mmx2500mm(49in x 98in) |
|
Thickness |
0.6mm- 50mm(0.024in x1.96in) |
|
Color |
Red,White,Grey,Brown,Yellow,Black or Customized color |
|
Production Capacity |
Max 300tons per month |
|
Appearance |
Surface is smooth,flat without bubbles and cracks |
|
Packing |
Wrapped with PP film outside and pallets with IPPC marks |
4. Application
GPO-33 rigid lamination sheets can be machined, punched, drilled, milled, sawed, sanded, sheared, or milled and have great mechanical strength. It is also feasible to assemble using glue, metal screws, or rivets. Our sheets pass the UL94 V0 flame test, and it also works well in electrical applications needing excellent arc and carbon trace resistance in addition to flame retardancy. It has good tracking resistance and is perfect for use in pole mounts, gaskets, control panels, and other applications that call for Class F materials because of its superior mechanical and thermal qualities.
5. General Applications:
|
Circuit Breakers |
Safety baffle,safety shutter,spacer,interphase partition that require insulating materials are flame retardant, heat resistance, weather resistance, high insulation performance, and mechanical strength. |
|
Motor Industry |
Used as motor armature parts, movable cover plate, slot wedge stator, fixed gasket, thin gasket, carbon brush plate. |
|
Switchgear Industry |
Used as switchgear clapboard, lining plate, arc extinguishing cover, arc extinguishing cylinder, arc extinguishing sheet, arc isolating plate, terminal block, interphase insulation, bottom end clapboard and contact support. |
|
Transformers Industry |
Used as structural supports of switches and transformers, bus clamps, etc. |
|
Traffic engineering |
In traffic transit such as rail and auto industry, there are many modules like motor, traction motor, or interior decoration that will use UPGM203 parts that required safety performance flame retardant V0 grade, temperature resistance Class F or above. |
|
Wind Power Generation |
When wind power generation generating electricity,UPGM203 parts are mostly used in wind energy motors. |
|
Solar Industry |
The photovoltaic system is composed of photovoltaic modules, bus boxes, inverter cabinets, distribution cabinets, transformers, and power grids. UPGM203 sheet used for supporting, load-bearing, and isolation in inverter cabinets, distribution cabinets, bus cabinets, and switch cabinets. |
6. Technical Data Sheet
|
No. |
Testing Item |
Measurement |
Requirement |
Result |
Testing Methord |
|
|
1 |
Tensile Strength |
MPa |
130 |
ASTM D638-14 |
||
|
2 |
Tensile Modulus of Elasticity |
MPa |
____ |
9.07x103 |
||
|
3 |
Flexural Strength |
MPa |
—— |
230 |
ASTM D790-17 |
|
|
4 |
Vertical Compression Strength |
MPa |
____ |
306 |
ASTM D695-15 |
|
|
5 |
Vertical Electrical Strength(Rapid Rise in normal oil) |
MV/m |
____ |
23.7 |
ASTM D149-09 （2013） |
|
|
6 |
Vertical Flashover Voltage (Rapid Rise in the air) |
KV |
____ |
38.1 |
||
|
7 |
Parallel Puncture Voltage(Rapid Rise in normal oil) |
KV |
____ |
81.0 |
||
|
8 |
Arc Resistance |
S |
—— |
182 |
ASTM D495-14 |
|
|
9 |
Comparative Tracking Index |
____ |
____ |
CTI 600 |
ASTM D3638-12 |
|
|
10 |
Insulation Resistance |
Normal |
Ω |
—— |
5.7x1013 |
ASTM D257-14 |
|
24H in Water |
1.7x1012 | |||||
|
11 |
Flammability |
Grade |
—— |
V-0 |
UL 94:20065 |
|
|
12 |
Oxygen Index |
% |
32.3 |
ASTM D2863-10 |
||
|
13 |
Water Absorption |
% |
—— |
0.27 |
ASTM D570-98 |
|
|
14 |
Density |
g/cm3 |
1.74 |
ASTM D792-13 |
||
|
15 |
Coefficient of Thermal Expansion(20℃-100℃) (Parallel) |
10-6/℃ |
—— |
23.5 |
ASTM D696-16 |
|
|
16 |
Thermal Conductivity(60℃) |
W/m·K |
0.605 |
ASTM C518-17 |
||
|
17 |
Heat Distortion Temperature |
℃ |
____ |
>240 |
ISO 75-1:2013 |
|
|
18 |
Flammability |
Grade |
____ |
V-0 |
UL 94-2013 |
|
7. Our Certificate
We have passed ISO9001 Quality Management Mystem, ISO14001 Environmental Management System, and our UPGM203 and SMC Insulation Sheet have certified by RoHS and Reach certification.
8.Our Overseas Exhibition
We actively participated in foreign related industry exhibitions, such CWIEME in Germany and Shanghai,AEC in France,Big5 in Dubai and Elecrama in India to bring our customers the best insulation products.
9. Packing and Delivery
We provide our customers with strong kraft paper and belt to ensure the safety of packing,also use PP film wrapped outside to avoid the damage and moisture in transit. We use wooden pallets with IPPC marks and fumigation certificate, which fully meet the importing countries crequirements.
